CCEWOOL® Stone Wool Multipurpose Board 40/60 is a high-performance, multipurpose stone wool insulation board designed for soundproofing and thermal insulation in walls, ceilings, and floors. The product is widely used in various applications, such as isolating mechanical rooms, storage spaces, and enhancing soundproofing and fire barriers. CCEWOOL® Stone Wool Multipurpose Board offers different density options to meet the specific needs of various projects, ensuring outstanding performance and reliability.
Combining excellent fire resistance, soundproofing, and moisture resistance, CCEWOOL® Stone Wool Multipurpose Board 40/60 provides long-lasting protection for modern buildings while creating a more comfortable and quiet indoor environment.
Outstanding Fire Performance: Made from non-combustible materials, it effectively prevents flame spread and avoids toxic smoke generation, providing a reliable fire barrier to safeguard occupants.
Excellent Acoustic Performance: With superior sound absorption capabilities, it significantly reduces noise transmission, enhancing the quietness of work environments and promoting a more efficient working and living experience.
Waterproofing Capability:The material does not absorb water and allows vapor to pass through, preventing moisture accumulation that could damage the structure, ensuring long-term stability for the building.
Long-Lasting Durability:Resistant to mold and bacteria, the material retains stable performance over time, does not decay or get damaged easily, providing long-term protection and ensuring the safety and health of the building.
Features:
Non-Combustible, Reliable Fire Protection;
No Smoke or Flame Spread, Enhancing Safety;
Excellent Dimensional Stability, Adapting to High-Temperature Environments;
Low Thermal Conductivity, Optimizing Building Energy Efficiency;
Water and Moisture Resistant, Maintaining Long-Term Performance;
Corrosion and Mold Resistance, Ensuring a Healthy Environment.
Applications:
Perimeter fire systems;
Fire insulation for construction joints;
Penetration protection;
Other fire protection applications.
CCEWOOL® Stone Wool Multipurpose board 40/60 |
||||||||
Product |
Rock Wool Multipurpose board 40 |
Rock Wool Multipurpose board 60 |
||||||
Density |
4 lb/ft³ (64 kg/m³) |
6 lb/ft³ (96 kg/m³) |
||||||
Dimensional stability |
Linear Shrinkage - <1% @ 1200°F |
|||||||
Dimensions |
24" x 48" (610 mm x 1219 mm) |
|||||||
Thickness |
1” through 4” (25.4 mm – 101.6 mm) |
2” through 4” (50.8 mm – 101.6 mm) |
||||||
Reaction to fire |
Class A Non-Combustible |
|||||||
Thermal resistance |
4.2 hr.ft2.F/Btu |
4.3 hr.ft2.F/Btu |
||||||
Reaction to moisture |
Moisture Sorption - 0.03% |
|||||||
Compressive strength |
90 psf (4.3 kPa) @ 10% compression |
355 psf (17 kPa) @ 10% compression |
||||||
225 psf (10.8 kPa) @ 25% compression |
585 psf (28 kPa) @ 25% compression |
|||||||
Corrosion Resistance |
No corrosion |
|||||||
Acoustical Performance |
Thickness |
125 Hz |
250 Hz |
500 Hz |
1000 Hz |
2000 Hz |
4000 Hz |
NRC |
1" |
0.07 |
0.32 |
0.77 |
1.04 |
1.05 |
1.05 |
0.8 |
|
1.5" |
0.18 |
0.48 |
0.96 |
1.09 |
1.05 |
1.05 |
0.9 |
|
2" |
0.26 |
0.68 |
1.12 |
1.1 |
1.03 |
1.04 |
1 |
|
3" |
0.63 |
0.95 |
1.14 |
1.01 |
1.03 |
1.04 |
1.05 |
|
4" |
1.03 |
1.07 |
1.12 |
1.04 |
1.07 |
1.08 |
1.1 |
