CCEWOOL® Stone Wool Sound Board is a high-performance stone wool insulation material designed for interior partitions in residential wood and steel stud structures that require exceptional fire resistance and acoustic performance.
This product is non-combustible and, even when directly exposed to flames, will not emit toxic smoke or contribute to fire spread. This critical property provides valuable extra time for evacuation and firefighting operations, ensuring reliable building safety.
CCEWOOL® Stone Wool Sound Board also delivers outstanding acoustic performance. It can be easily integrated with walls, ceilings, and floors to significantly reduce noise transmission, helping create a quieter and healthier indoor environment.
As an ideal solution for enhancing both fire safety and acoustic performance, this product also carries strong environmental attributes, making it a preferred choice for modern residential and commercial buildings.
Easy to cut: Flexible and easy to handle, enabling precise cutting to fit various installation needs.
Non-combustible: High melting point provides superior fire protection for buildings.
Excellent sound absorption: Outstanding acoustic properties effectively reduce noise transmission and optimize indoor acoustic environments.
High-melting fire resistance: Heat-resistant material maintains stability in fire situations, providing additional evacuation time.
Mold- and fungus-resistant: Will not rot or support mold or fungal growth, ensuring a healthy building environment.
Low moisture absorption: Low water uptake resists moisture effects and maintains insulation performance.
Water- and moisture-resistant: Repels water and prevents absorption, ensuring long-term insulation and fire performance.
Interior wood or steel stud partition walls;
Interior wood structure floors;
Interior wood structure ceilings;
I-joist interior partitions;
Party walls.
|
CCEWOOL® Stone Wool Sound Board |
||||||||
|
Density |
38 kg/m³ (2.4 lb/ft³) |
|||||||
|
Reaction to fire |
Class A Non-Combustible |
|||||||
|
Acoustical Performance |
Thickness |
125 Hz |
250 Hz |
500 Hz |
1000 Hz |
2000 Hz |
4000 Hz |
NRC |
|
3" |
0.52 |
0.96 |
1.18 |
1.07 |
1.05 |
1.05 |
1.05 |
|
|
Product Range |
||
|
Thickness (inch) |
Width (inch) |
Length (inch) |
|
3 |
15.25 |
47 |
|
3 |
16.25 |
48 |
|
3 |
19.2 |
47 |
|
3 |
23 |
47 |
|
3 |
24.25 |
48 |
|
6 |
15.25 |
47 |
|
6 |
16.25 |
48 |
|
6 |
19.2 |
47 |
|
6 |
23 |
47 |
